| Brand Name | Wecantester |
|---|---|
| Place of Origin | |
| Standards | BIFMA X5.5-2021, BIFMA X5.6-2010, BIFMA X5.9-2019 |
| topic | Standard | chapter | Chapter title | |||
| standard | BIFMA X5.5-2021 | 10 | Desk and Table -Extendible Element Cycle Tests | |||
| 17.7 | Desk and Table -Fatigue Test for Vertical Receding Doors | |||||
| 17.8 | Desk and Table -Fatigue Test for Horizontal Receding Doors | |||||
| BIFMA X5.6-2010 | 10.2/3 | Cycle Test for Extendible Elements | ||||
| 10.4 | Cycle Test for Center/Pencil Drawers. | |||||
| 11.7/8 | Wear and Fatigue Test for Vertical & Horizontal Receding Door. | |||||
| BIFMAX5.9-2019 | 15 | Extendible Element Cycle Tests. | ||||
| 17.7/8 | Wear and Fatigue Test for Vertical & Horizontal Receding Door | |||||
| Features | 1. Servo motor drive, supporting tension and pressure sensor, programmed test process. 2. The automatic simulation loading determines the starting point and the ending point, and the distance between the turning point and the front and rear blocking points can be set. 3. It has the function of reversing buffer and deceleration, and the reversing is stable and reliable. 4. Programmatically set sub-speed loading process. 5.The horizontal loading height is adjusted electrically, and the position is self-locked at any position. 6.Universal foot pad equipment, so that the minimum distance between the equipment and the ground is greater than80mm for easy adjustment of equipment level and forklift handling. | |||||
| control | 1. Servo control, using Panasonic AC servo motor and servo driver. 2. Using Keli brand pull pressure sensor. 3. Input and output test parameters through the Weillon touch screen. 4.With stop/breakpoint memory function to avoid loss of test data. | |||||
| parameter | 1.The guide rail stroke can be set:80-580 mm; 2.Adjustable horizontal loading height200-1600 mm (height depends on the height of the mounting frame); 3.Configurable counter:6 Bit, the reset button has misoperation protection; 4.X-shaped size:1200*850*1970mm,177Kilogram. power supply:220VAC 5AO | |||||
| Non-standard accessories | Numbering | name | quantity | use | ||
| WT-BFM-24+B01 | Standard drawers and support structures | 1set | Use of test rail accessories | |||
| WT-BSE-36 | Drawer Test Glass Balls (Bag) | 1set | Load the tested drawer | |||
