| Brand Name | Wecantester |
|---|---|
| Place of Origin | |
| Standards | ASTM F963-11 4.9 16 CFR 1500.48 GB 6675.2-2014 5.9，5.14; BS EN 71-1:2011 8.12.2 ST 2002-2009 ISO 8124-1:2010 5.9 |
Function:
Detecting whether there are sharp points that endanger safety at the accessible position of the product is a safety test item.
| model | WT-CHP-19-US | WT-CHP-19-EG | |||
| standard | ASTM F963-11 4.9 16CFR 1500.48 | GB 6675.2-2014 5.9, 5.14; BS EN 71-1:2011 8.12.2 ST 2002-2009 ISO 8124-1:2010 5.9 | |||
| the difference | Spring Force Finishing Weight: Test Hole Size Tolerance Test Hole Depth Tolerance: | Spring Force Finishing Weight: Test Hole Size Tolerance Test Hole Depth Tolerance: | |||
| Features | 1.The axial clearance of the bottom cover thread for adjusting the test clearance of key accessories is less than2 Silk; 2. Made of stainless steel material, never rust. 3.use1Festival5No1.5 Volt dry battery power supply; 4.The bottom cover (key metering accessories) is laser engraved with a permanent unique number, which is convenient for metering records and plugging fake loopholes. | ||||
| parameter | 1.The bottom cover is marked with tick marks, and each time it is rotated relative to the tester body1A scale represents the axial adjustment0027mm. When the indicator light is at the critical point, turn it counterclockwise5 grid, that is, the gap set for the standard requirements. 2.The total weight of the weight of the heavy stone and the tester is1 Pounds are the force exerted on the sample being tested during the test; 3.Product packaging size:210*145*75mm, gross weight:0.85Kilogram. | ||||
| Standard accessories | Numbering | name | quantity | use | |
| NA | 1.5VDCLight bulb | 2indivual | spare1parts, installed on the product1piece | ||
| NA | 1Pound counterweight broken code | 1indivual | Counterweight, so that the overall self-weight of the test is equal to the test loading force, which is convenient for operation. | ||
| NA | 3mm hex key | Disassembly and reassembly | |||
| NA | 5No1.5Volt dry battery | 1indivual | powered by | ||
| Purchase attention | 1. International orders do not come with batteries, because international express prohibits products with batteries. 2.The most important accessory of the sharp tip tester is the bottom cover/concentrates multiple dimensions that require precision machining. When our factory produces this accessory, we use laser marking to permanently retain the unique tracking identification number. | ||||
